P/N: 2104801.00 SIRIO 827 Electrical Data: Type: 5/8 λ ground plane Radiation: Omnidirectional Polarization: Linear vertical Frequency range: 26.4 ... 28.4 MHz Tunable Systems: 10m-HAM Gain: 1.5 dBd, 3.65 dBi Bandwidth: ≥ 2MHz @ SWR ≤ 2 Max Power: 1000 Watts (CW) continuous3000 Watt
Producent: Sirio
Tags: Sirio Sirio 827 CB antenne CB zender CB basis antenne 27Mhz
Specs Sirio 827
| P/N: 2104801.00 | SIRIO 827 |
Electrical Data:
| Type: | 5/8 λ ground plane |
| Radiation: | Omnidirectional |
| Polarization: | Linear vertical |
| Frequency range: | 26.4 ... 28.4 MHz Tunable |
| Systems: | 10m-HAM |
| Gain: | 1.5 dBd, 3.65 dBi |
| Bandwidth: | ≥ 2MHz @ SWR ≤ 2 |
| Max Power: | 1000 Watts (CW) continuous 3000 Watts (CW) short time |
| Grounding protection: | DC-Ground |
| Connector: | UHF-female (SO-239) PL-259 |
Mechanical Data:
| Materials: | Aluminium, Copper, Galvanized steel, Nylon |
| Height (approx): | 6700 mm / 21.98 ft |
| Weight (approx): | 6000 gr / 13.23 lb |
| Mounting type: | On-Mast |
