Product Omschrijving

MODEL: HIKVISION DS-KIS603-P

Videofoon Wifi UTP set

Hikvision is een fabrikant van hoogwaardige camerabewaking en videofonie. Met deze set heb je kwaliteit in huis gehaald. Het is mogelijk om hem te gebruiken als een traditionele set maar ook via je smartphone of tablet. Op deze manier kan je steeds te woord staan als er iemand aan je deur staat...waar u zich ook maar bevind in de wereld.

Het systeem is ook perfect uitbreidbaar met camerabewaking van Hikvision. Op deze manier kan je via het schermpje van je videofoon ook de beelden van je camera's raadplegen en alles in één geheel bedienen via je App op je smartphone of tablet.

Wenst u assistentie of een professionele plaatsing dan u steeds op onze plaatsingsdienst rekenen.

Bel Bea electronics op het nr 089/380195 of stuur een mail naar support@bea-electronics.be

Includes:

• IP video intercom kit for villa or house, only one call button;
• DS-KV6113-WPE1 x1;
• DS-KH6320-WTE1 x1;
• PSU x2;

Specifications

System Parameters

• Operation Method: Physical button(DS-KV6113-WME1)
• Operation System: Embedded Linux operation system(DS-KV6113-WME1)
• Flash: 32MB(DS-KV6113-WME1)
• RAM: 97055c49-573b-485c-a76c-d318a8fc6ab4256MBoverseas

Alarm Parameters

• Tampering Alarm: 1(DS-KV6113-WME1)

Network Parameters

• Ethernet: 10/100 Mbps Ethernet(DS-KV6113-WME1)
• Network Protocol: TCP/IP, RSTP(DS-KV6113-WME1)
• Wifi: 2.4GHz Wi-Fi(DS-KV6113-WME1)

Audio Parameters

• Audio Input: Built-in omnidirectional microphone(DS-KV6113-WME1)
• Audio Output: Built-in loudspeaker(DS-KV6113-WME1)
• Audio Compression Standard: G.711 U(DS-KV6113-WME1)
• Audio Compression Rate: 64 Kbps(DS-KV6113-WME1)
• Audio Quality: Noise suppression and echo cancellation(DS-KV6113-WME1)

General

• Power Supply: IEEE802.3af, standard PoE (DS-KV6113-WME1) 12 VDC(DS-KV6113-WME1)
• Working Temperature: -10 °C to 55 °C (14 °F to 131 °F)(DS-KH6320-WTE1)
• Indicator: 2(DS-KV6113-WME1)
• Working Humidity: 10% to 90%(DS-KH6320-WTE1)
• Power Consumption: ＜ 10 W(DS-KV6113-WME1)
• Dimension (L X W X D): 174 mm × 91 mm × 29 mm(DS-KV6113-WME1)
• Installation: Surface mounting/ Flush mounting(DS-KV6113-WME1)
• Working Temperature: -40° C to 53° C(-40° F to 127.4° F)(DS-KV6113-WME1)
• Working Humidity: 10% to 95%(DS-KV6113-WME1)
• Weight: 899 g (with packaging)(DS-KH6320-WTE1) 355 g (without packaging)(DS-KH6320-WTE1)
• Ingress Protection Level: IP65(DS-KV6113-WME1)
• Memory: 128 MB(DS-KH6320-WTE1)

Video Parameters

• Camera: 2MP HD Camera(DS-KV6113-WME1)
• Wide Dynamic Range: True WDR(DS-KV6113-WME1)
• Video Compression Standard: H.264(DS-KV6113-WME1)
• Resolution: Main stream: 1920 × 1080p, 720p Sub stream: 704 × 576(DS-KV6113-WME1)
• Night Vision: Low illumination IR supplement mode(DS-KV6113-WME1)
• Video Streaming: Main stream: 1080p@30fps, 720p@25fps Sub stream: D1@25fps(DS-KV6113-WME1)
• Field Of View: Horizontal: 129° Vertical: 75°(DS-KV6113-WME1)

Device Interfaces

• Alarm Input: 4(DS-KV6113-WME1)
• Button: 1(DS-KV6113-WME1)
• TF Card: Max to 32G(DS-KV6113-WME1)
• Relay For Lock: 1(DS-KV6113-WME1)

Event

• Motion Detection: Support(DS-KV6113-WME1)

Camera Parameters

• BLC: Support(DS-KV6113-WME1)
• Field Of View: Horizontal: 129° Vertical: 75°(DS-KV6113-WME1)

Access Control Parameters

• Internal Card Reader: 13.56 MHz Mifare Card Reader (DS-KV6113-WME1)

Audio Parameters

• Audio Compression Rate: 64 Kbps(DS-KH6320-WTE1)
• Audio Compression Standard: G.711 U(DS-KH6320-WTE1)
• Audio Input: Built-in omnidirectional microphone(DS-KH6320-WTE1)
• Audio Output: Built-in loudspeaker(DS-KH6320-WTE1)
• Audio Quality: Noise suppression and echo cancellation(DS-KH6320-WTE1)

Device Interfaces

• RS-4851: (DS-KV6113-WME1)

Display Parameters

• Display Resolution: 1024 × 600(DS-KH6320-WTE1)
• Display Screen: 7-inch colorful IPS LCD(DS-KH6320-WTE1)

Network Parameters

• Network Protocol: TCP/IP, SIP, RTSP(DS-KH6320-WTE1)
