Sirio 27Mhz basis antenne VECTOR 4000

  • 109.95 €

Merk en type : Sirio 27Mhz basis antenne Vector 4000 Type: 3/4 λ coaxial J-pole Radiation: Omnidirectional Polarization: Linear vertical Frequency range: 27 ... 28.5 MHz Tunable Systems: 10m-HAM Gain: 2 dBd, 4.15 dBi Bandwidth: ≥ 1.4MHz @ SWR ≤ 2 Max Power: 1000 Watt


Producent: Sirio

Tags: Vector 4000 Sirio basis antenne CB antenne CB


Downloads

Vector 4000


Product Omschrijving

Merk en type : Sirio 27Mhz basis antenne Vector 4000

Type: 3/4 λ coaxial J-pole
Radiation: Omnidirectional
Polarization: Linear vertical
Frequency range: 27 ... 28.5 MHz Tunable
Systems: 10m-HAM
Gain: 2 dBd, 4.15 dBi
Bandwidth: ≥ 1.4MHz @ SWR ≤ 2
Max Power: 1000 Watts (CW) continuous
3000 Watts (CW) short time
Grounding protection: All metal parts are DC-grounded, the inner conductor is coupled capacitively
Connector: UHF-female (SO-239 PL-259)

Mechanical Data:

Materials: Aluminium, Brass, Galvanized steel, Nylon
Height (approx): 8480 mm / 27.82 ft
Weight (approx): 4700 gr / 10.36 lb
Mounting type: On-Mast
